ABB FS225R12KE3/AGDR-71C

ABB FS225R12KE3/AGDR-71C is an IGBT module produced by ABB, which combines IGBT (insulated gate bipolar transistor) and driver circuit, commonly used in power electronics inverter, motor drive and other applications. The module has been widely used in the field of industrial automation because of its high power density, fast switching speed and high temperature resistance.

Product name
English: ABB FS225R12KE3/AGDR-71C IGBT module

English: ABB FS225R12KE3/AGDR-71C IGBT Module
Product description
The FS225R12KE3/AGDR-71C module is an integrated circuit packaged in a single component, which contains multiple IGBT chips and driver circuits. The IGBT chip inside the module is responsible for the power switch, while the drive circuit provides the necessary control signals. The module is usually mounted on a radiator to ensure that it works properly.

Main features and advantages

High power density: Integration of multiple IGBT chips in a smaller package improves power density.
Fast switching speed: can quickly respond to control signals, improve the dynamic performance of the system.
High temperature resistance: suitable for harsh industrial environments.
High reliability: advanced packaging technology,
