ABB NTAI05

The ABB NTAI05 module is a high level analog input termination unit designed by ABB for its Bailey series industrial control systems. It is mainly used to receive the analog signal from the field and convert it into a standard electrical signal for connection to the analog input module of the controller.
​Product name
Full name: ABB NTAI05 High level analog input termination unit

English full name: ABB NTAI05 Analog Input Termination Unit High Level
Product description
The main functions of the NTAI05 module are:

​Analog signal reception: Receive a variety of high level analog signals from the field, such as 4-20mA, 0-10V, etc.
Signal isolation: Provides electrical isolation to protect the control system from field interference.
Signal conversion: The analog signal is converted into a standard electrical signal for connection to the analog input module of the controller.
Product parameters and specifications
The specific parameters of the NTAI05 module vary according to different configurations and applications, and generally include:
​Number of input channels: usually multiple channels, can receive multiple analog signals at the same time.
Input signal range: Support a variety of input signal ranges, such as 4-20mA, 0-10V, etc.
Accuracy: High measurement accuracy.
Isolation voltage: Provide sufficient isolation voltage to ensure system safety.
