ABB RINT-5411The ABB RINT-5411 module is a key component in ABB’s ACS800 series of drives, commonly referred to as the control drive board or drive board. It is responsible for the core functions of the inverter, such as control, driving and filtering, and is the guarantee of the normal operation of the inverter.
​Product name
Chinese full name: ABB ACS800 series inverter control drive board

Full name: ABB ACS800 Drive Control Board
Product description
The RINT-5411 module is the “brain” of the ACS800 inverter and integrates a variety of functions, including:
​Control function: to achieve the inverter parameter setting, operation mode switching, fault diagnosis and other control functions.
Drive function: Drive IGBT and other power devices, generate variable frequency voltage, so as to control the speed of the motor.
Filter function: Filter the input and output voltage to improve the electromagnetic compatibility of the system.

Protection function: to achieve overcurrent, overvoltage, overheating and other protection functions to ensure the safe operation of the inverter.
Product parameters and specifications (part)
Applicable inverter: ACS800 series
Function: control, drive, filter, protection
Voltage level: Depending on inverter model
Current level: depends on inverter model
Size: depends on inverter model and installation method
Main feature
High performance: Advanced control algorithm is adopted to achieve high performance motor control.
High reliability: The use of industrial components, with high reliability.
Modular design: easy maintenance and replacement.
Flexible configuration: It can be flexibly configured through programming software.
