ABB S-073N 3BHB009884R0021

ABB S-073N 3BHB009884R0021 module is a module with high performance and high reliability. It uses advanced modular multilevel converter (MMC) technology to achieve efficient energy conversion, reduce energy waste, and improve the overall operating efficiency of the equipment. In addition, the module also has an accurate phase control function, which is suitable for application scenarios requiring high precision control. Its powerful system capability enables it to operate stably in high-voltage frequency conversion systems and adapt to a variety of complex environments1.

In the design, the ABB S-073N 3BHB009884R0021 module uses IGCT (Integrated gated thyristor) technology, which helps improve energy efficient3. At the same time, its press-mounted design allows the module to be installed directly between two radiators, allowing for effective bilateral cooling2.

In some applications, the ABB S-073N 3BHB009884R0021 module is described as a servo driver with a wide input voltage range, high output power, wide current regulation range, and support for multiple control modes such as position control, speed control, and torque control3.

Product parameters and specifications:

Input voltage range: In the application of servo drives, DC 200-750 volts 3 is supported.
Output power: up to 750 watts (when used as a servo drive) 3.
Current regulation range: from 0 to 3 amps (when acting as a servo driver) 3.

Control mode: Support position control, speed control, torque control and other modes 3.
Pulse input frequency: up to 5 MHZ (when used as a servo driver) 3.
Encoder input function: provides precise position feedback and control3.
Communication function: DCS-Link communication function is used to realize the direct exchange of data between the drive 3.
Circuit design: three-level circuit design, composed of multiple IGCT 3.
