Agilent 5517B

The 5517B laser head module provides the following functions:

Stable laser output: Provides single-mode, highly stable helium-neon laser output.
Wide application: Can be used for optical measurement, calibration, alignment and other applications.
Compact design: Compact and easy to integrate into various optical systems.
Product parameters and specifications (typical values)
Wavelength: 633 nm (red)
Output power: 180μW to 1mW
Beam diameter: about 6mm

Beam height: approx. 79.5mm
Operating temperature: 0℃ to 40℃

Reference frequency: 1.9 MHz to 2.4 MHz
Note: Specific parameter values may vary according to different production batches and configurations. Please refer to the product data manual.

Potential use
Optical measurement: Light source for various optical measuring instruments, such as interferometers, optical meters, etc.
Calibration: Used to calibrate optical instruments and sensors.
Alignment: Used for optical system alignment.
Scientific experiments: Light sources used in optical experiments.
Matters needing attention
Power requirements: Suitable power supply should be provided according to the product instructions.
Environment requirements: Pay attention to the operating temperature and humidity range.
Safety precautions: The laser beam is harmful to the eyes, please wear protective glasses when using.
