AMAT 0090-76110 VME PCB

The AMAT 0090-76110 module is a VME bus board manufactured by Applied Materials (AMAT). VME (Versa Module Eurocard) is an industry standard modular bus, widely used in industrial control, data acquisition and signal processing fields. The AMAT 0090-76110 module is usually used as part of a large industrial equipment or automation system for a specific control or data processing function.

Product description
The AMAT 0090-76110 module is an SBC (Single board computer) circuit board with specific features and configurations that vary depending on the device. In general, it will contain the following components:

Processor: A high-performance microprocessor used to execute control programs.
Memory: Used to store programs and data.
Interface: VME bus interface, used to communicate with other modules in the system.
Other ports: Serial ports, parallel ports, and Ethernet ports are used to connect other devices.
Product parameters and specifications (possible values, subject to official data)
Processor: The specific model and frequency vary depending on the version, and may be PowerPC, ARM, or another type of processor.
Memory: The capacity of DRAM and ROM varies depending on the configuration.
VME bus: conforms to the VME bus standard and supports different bus widths and transmission rates.
Interfaces: In addition to the VME bus, other interfaces may be supported, such as RS-232, RS-485, Ethernet, etc.
Operating temperature: -20 ° C to +70 ° C (specific range may vary by model).
Size: Size according to VME standard.
Application field
The AMAT 0090-76110 module is mainly used in semiconductor manufacturing equipment. It may be used for:

Process control: control all aspects of the equipment, such as temperature, pressure, flow, etc.
Data collection: Collect equipment operation data for monitoring and analysis.
Man-machine interaction: provides man-machine interaction interface to facilitate the operator to set and monitor.
