AMCI 7264

AMCI 7264 is a SSI (Synchronous Serial Interface) interface module designed for the Allen-Bradley ControlLogix

platform. It can connect up to four independent SSI output sensors, convert the position, speed and other data collected by the sensor into digital signals, and transmit them to the PLC for processing. The module is widely used in various industrial automation systems for precise position control, motion control and other applications.

Product parameters and specifications (specific parameters may vary

depending on the model and configuration, please refer to the official data)
Number of channels: Four independent SSI interface channels
Interface type: SSI (Synchronous Serial interface)
Sensor types: Support a variety of SSI output types of sensors, including incremental encoders, absolute encoders, and more
Resolution: Supports high resolution sensors
Communication protocol: SSI protocol
Power supply: 24VDC
Installation method: Plug-in, directly installed on the ControlLogix controller rack
Environmental conditions: Suitable for industrial environment, with high anti-interference ability
Main function
Sensor interface: Connects to sensors of SSI output type.
Signal conversion: Converts SSI signals to digital signals.
Data transmission: The digital signal is transmitted to the PLC.
Parameter configuration: Configure the parameters of the module through the software, such as the sensor type and resolution.
Fault diagnosis: It has the fault diagnosis function to facilitate users to discover and remove faults in time.
