The B&R 3IP161.60-1 is a powerful programmable I/O processor from the B&R System 2005 family. It integrates digital input/output, analog input/output and other functions, and can flexibly connect various sensors and actuators, and is widely used in automatic control systems.

Product parameters and specifications:

Model: 3IP161.60-1
Series: System 2005
processor: 2005 programmable I/O processor
Memory: 850 KB SRAM, 1.5 MB FlashPROM
Interface: 1 RS232 interface, 1 CAN interface (electrical isolation, support network)
Digital input: Max 12 channels, 24 VDC, sink
Digital output: Max 12 channels, 24VDC, 0.1A
Analog input: 6 channels, ±10 V, 14-bit resolution
Analog output: 6 channels, ±10 V, 12 bit resolution
Other: 2 outputs with +10 V and -10 V on each output terminal block, 3x TB170 terminal block must be ordered separately
Product features:
High integration: Integrates multiple I/O functions to save space.
High performance: Powerful processor and abundant memory for fast response.
Flexible configuration: The I/O function can be flexibly configured based on application requirements
