FOXBORO FBM214

The Foxboro FBM214 is A HART input module for I/A series systems. HART (Highway Addressable Remote Transducer) is an intelligent field instrument communication protocol. The FBM214 module can communicate with various HART devices such as temperature sensors, pressure sensors, etc. The measured value of HART equipment is converted into a standard digital signal and transmitted to the control system.
​Product parameters and specifications (typical values, refer to the product manual)
Number of channels: Generally 4 channels or 8 channels, depending on the model
Input type: HART

Signal types: 4-20mA, 0-20mA
Sampling rate: Configurable
Diagnostic function: Supports the diagnosis and configuration of HART devices
Isolation: Channels are isolated from each other
Power supply: 24V DC

Operating temperature: 0°C ~ 55°C
Mounting method: DIN rail mounting
peculiarity
High accuracy: The measurement values of HART devices can be accurately collected.
Multi-channel design: A module can simultaneously collect signals from multiple channels.
Flexible configuration: Multiple HART devices and different configuration options are supported.
Powerful diagnostic function: HART equipment can be diagnosed and configured for easy maintenance.
