GE 469-P5-HI-A20-E

The GE 469-P5-HI-A20-E is a motor protection relay in the General Electric Multilin 469 series for monitoring, controlling and protecting medium and large motors. It has the following characteristics:

Multiple protection functions, including over current, over voltage, under voltage, single phase, reverse phase, ground fault, etc
Measure and record motor operating parameters, such as current, voltage, power, power factors, etc

Communication function, can be connected to the upper system or SCADA system
Programmable, customized protection and control logic according to user needs
Product parameters:

Rated current: 5A
CT secondary current: 5A
Auxiliary voltage: 90-300 VDC, 70-265 VAC

Frequency: 48-62 Hz
Analog output: 4-20 mA
Other functions: event recording, fault wave recording, RS232/RS485 communication
Specifications:

Dimensions: 144 x 144 x 58 mm
Weight: About 1.2kg
Mounting method: panel mounting or DIN rail mounting
Enclosure protection class: IP65
Applications:

GE 469-P5-HI-A20-E modules are used in a wide range of industrial applications, including:

Oil and gas
electricity
Water treatment
metallurgy
papermaking
spin
Food processing
Rubber and plastic
