GE DS200AAHAH1AED

Information about the GE DS200AAHAH1AED module is as follows:

Product Name:
GE DS200AAHAH1AED module

Product Description:
The GE DS200AAHAH1AED module is an ARCNET LAN driver created by GE (General Electric) for use as part of the Mark VLM series Speedtronic hardware12. It is a PCB for the MARK V control panel, also identified as ARCNET Connector Board (AAHA) 1. The main function of the DS200AAHAH1AED module is to play a role in the control panel of the Mark V, connecting the main control engine and external drives to the ARCNET connection, allowing the control engine

to communicate with the I/O core and allowing connection to the user interface 2.

Product parameters and specifications:
The DS200AAHAH1AED module has three communication ports, of which the EBNC port is not used, Arcbnc-A and Arcbnc-B ports are available. There is a 2pl connection port in the bottom right corner of the top plane, an APL10 pin connection port in the center, and also an unused ELS connection 2 in the bottom left corner. In addition, the module has the following specification features:

Power requirements: +9V ~ +35Vdc3

Power consumption: 1W3
Isolation voltage: 3000Vdc3
Transmission speed: Support a variety of rates, including 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200bps3
Connector type: 9PIN D-SUB (Receptacle) 3
Terminal type: Accepts AWG1-#12 to #24 wire 4
Dimensions: (L x W x H) 118mm x 71mm x 22m
