GE 369-HI-R-M-0-0

GE 369-HI-R-M-0-2-0-0 is the Multilin 369 series of medium voltage motor protection relays from General Electric (GE), designed to protect medium voltage AC motors from a variety of failures. The relay has the following features:

High reliability: Rugged design to withstand harsh environments.

High performance: provides a variety of protection functions, can effectively protect the safety of the motor.
Easy to use: provides intuitive interface and programming software, easy to configure and use.
Product parameters:

Voltage range: 50-300 VDC or 60-265 VAC
Frequency: 50/60 Hz
Rated current: Available 5A, 10A, 20A, 30A, 50A, 75A, 100A, 150A, 200A, 300A, 400A, 500A, 600A, 800A, 1000A, 1200A, 1500A, 2000A
Protection function: over current, over voltage, under voltage, unbalanced load, single-phase grounding, phase deficiency, reverse phase, harmonic, oscillation, circuit breaker failure, motor overheating, bearing failure, etc
Communication interface: RS-232, RS-485, Ethernet
Supported protocols: Modbus TCP/IP, SRTP, OPC UA, EGD, PROFINET, DNP3 Outstation, IEC-61850 Client, and IEC-104 Server
Operating temperature: -40°C to +70°C
Protection level: IP67
Dimensions: 230 x 167 x 64 mm
Weight: About 2.5kg
Product Specifications:

Comply with IEC 60255-5 standard
Supports DIN rail mounting
Application field:

Power station
substation
Factory automation
Oil and gas
mining
