GE HE693ADC409

Product Name: GE HE693ADC409 Millivolt Input Module

Product Description:

The GE HE693ADC409 is a millivolt input module designed for the GE Series 90-30 Programmable Logic Controller (PLC) system. It provides four isolated analog input channels specifically for millivolt signals and strain gauge (load cell) inputs. This module allows the PLC to interface with and read signals from various low-voltage sensors and transducers. Each of the four channels can be individually configured for different input ranges.

Key Features:

• Four isolated analog input channels.
• Specifically designed for millivolt and strain gauge inputs.
• Supports bridged (load cell) strain gauges.
• Individually configurable input ranges: +/-250mV, +/-500mV, and +/-1000mV (1V).
• High input impedance (>20 Mohms).
• Common mode range of +/-12VDC.
• High accuracy.

Product Parameters:

• Manufacturer: GE Intelligent Platforms (now part of Emerson)
• Series: Series 90-30
• Model Number: HE693ADC409
• Number of Channels: 4
• Input Range (VDC): +/-250mV, +/-500mV, +/-1000mV (1V)
• Input Impedance: >20 Mohms
• Maximum Safe Overload: +/-35VDC
•
• Common Mode Range: +/-12VDC
• A/D Conversion Type: Integrating
• Module Update Rate: 35 channels per second
• Resolution: 30µV (+/-250mV range), 60µV (+/-500mV range), 90µV (+/-1000mV range)
• Accuracy: +/-0.05%
