GE HYDRAN M2

The GE HYDRAN M2 module is a smart device designed for online transformer monitoring. By continuously monitoring the concentration of dissolved gas in the transformer oil, it assesses the operation status of the transformer and warns of potential failures in advance

to ensure the safe and reliable operation of the transformer.

Product Name:
GE HYDRAN M2 on-line monitoring system for dissolved gas in transformer oil
Product description
The HYDRAN M2 is a compact, permanently installed on-line transforme

r monitoring device. It can continuously monitor the concentration of various fault gases in the transformer oil, and based on these data, analyze the types of faults that may occur inside the transformer. By early detection of potential failures, appropriate maintenance measures can be taken to avoid sudden failures, reduce downtime, and reduce maintenance costs.

Main function
Dissolved Gas Analysis (DGA): Continuous monitoring of the concentration of dissolved gases in transformer oil, including hydrogen, methane, ethane, ethylene, acetylene, etc.
Fault diagnosis: According to DGA data, analyze the types of faults that may occur inside the transformer, such as overheating, partial discharge, arc discharge, etc.
Alarm function: When abnormal situation is detected, sound and light alarm is issued, and the alarm information can be sent to the upper computer through the communication interface.
Data logging: The monitoring data is stored inside the device for easy later analysis and review.
Communication function: supports a variety of communication protocols, and can exchange data with the host computer.
