GE HYDRAN M2

GE HYDRAN M2 module: Details in Chinese
Product name
GE HYDRAN M2 module: This is an online transformer monitoring device manufactured by General Electric (GE). The Hydran M2 is the model for monitoring the content of dissolved gases in transformer oil.
Product description

Transformer Monitoring Equipment: The Hydran M2 is a compact, permanently installed on-line transformer monitoring equipment. By continuously monitoring the content of dissolved gases in the transformer oil, it can provide early warning of possible failures within the transformer, thereby reducing downtime and economic losses.
Dissolved gas analysis: The Hydran M2 continuously monitors the composite value (ppm) of various faulty gases in the transformer oil or only the hydrogen value (depending on the sensor purchased). In addition, it can also monitor the moisture content of the oil.

Failure warning: Through the analysis of monitoring data, the Hydran M2 is able to identify possible faults within the transformer, such as overheating, partial discharge, arc, etc., and issue an alarm to remind maintenance personnel to take timely measures.
Product parameters and specifications
The main parameters and specifications of the Hydran M2 module are as follows (specific parameters may vary slightly depending on the model and configuration) :

Measuring gases: hydrogen, methane, ethane, ethylene, acetylene, etc.
Measuring range: Different gases have different measuring ranges, please refer to the product data manual for details.
Accuracy: High measurement accuracy, can accurately reflect the content of dissolved gas in transformer oil.
Response time: The response time is fast, and the change of gas content can be detected in time.
Communication interface: supports a variety of communication methods to facilitate data transmission with the host computer.
Power requirements: Power supply voltage and current required by the module.
Environmental conditions: module operating temperature, humidity range and anti-interference capability.
Size: The physical size of the module.
Product characteristics
Continuous monitoring: The content of dissolved gas in transformer oil can be monitored in real time.
Fault warning: It can warn the transformer of possible faults in advance.
Easy to install: Compact module design, easy to install.
High reliability: high reliability sensors and electronic components.
