GE HYDRAN M2

The GE HYDRAN M2 module is a device specifically designed for online transformer monitoring. It continuously monitors the composition and content of dissolved gas in the transformer oil to evaluate the possible faults inside the transformer, so as to warn in advance, avoid power outage accidents caused by sudden failures, and ensure the safe and reliable operation of the power system.

Product name
GE HYDRAN M2 Analyzer for dissolved gases in transformer oil

HYDRAN M2 online monitoring system
Product description
The HYDRAN M2 module is a compact, permanently installed on-line transformer monitoring device. It monitors the concentration of various fault gases in transformer oil through sensors in real time, and analyzes these data to determine the type and severity of faults that may occur inside the transformer.

Main function

Gas concentration monitoring: Continuously monitor the concentration of hydrogen, methane, ethane, ethylene, acetylene and other fault gases in transformer oil.
Fault diagnosis: According to the trend and combination of gas concentrations, determine the types of faults that may occur inside the transformer (such as overheating, partial discharge, arc, etc.).
Alarm function: When the fault symptom is detected, the alarm signal is sent in time to remind the maintenance personnel to check.
Data logging: Monitoring data is stored for historical analysis and trend analysis.
Remote monitoring: Remote monitoring and data transmission can be achieved through the communication interface.
Product parameters (part)
Measuring gases: hydrogen, methane, ethane, ethylene, acetylene, etc
Measuring range: According to the specific model and configuration
Accuracy: High precision sensor to ensure accurate and reliable measurement results
Interfaces: RS485, Modbus, etc
