GE IC693ALG221

The GE IC693ALG221 is an analog input module designed for General Electric Series 90-30 Programmable Logic controllers (PLCS). It is mainly used to collect analog current signals in industrial processes, such as 4-20mA current signals, and convert these analog signals into digital signals for PLC processing and control. The module is usually installed in the chassis of Series 90-30 PLC, and is used in combination with other modules to form a complete control system.

Product parameters and specifications:
Model: IC693ALG221
Type: Analog current input module
Number of channels: 4
Input signal: 4-20mA analog current signal
Resolution: High resolution to provide accurate measurement results
Isolation: There is electrical isolation between channels to improve anti-interference ability
Power supply: From Series 90-30 PLC bus

Communication: Communication with PLC via Series 90-30 bus
Update rate: The conversion speed of each channel is 0.5 ms, and the update rate of any channel is 2 ms
Main features:
High accuracy: Provides accurate analog current measurement.
High reliability: Designed for industrial environments with high reliability.
Modular design: easy installation and maintenance.
High-speed conversion: Fast conversion speed, good real-time.
Isolation design: improve the anti-interference ability of the module.
