GE IC693MDL740

The GE IC693MDL740 module is mainly used to provide digital output function in PLC control system. It can convert the digital signal inside the PLC into the actual control signal, so as to drive external devices, such as relays, motors, etc. The module has the characteristics of high reliability and fast response speed, and is widely used in industrial automation, process control and other fields.

Product parameters and specifications:
Model: IC693MDL740
Type: Digital output module

Voltage: 12/24VDC

Logical type: positive logic
Output current: 0.5A/ channel
Number of channels: 16 (2 groups, 8 channels per group)
Response time: 2ms (Max)
Operating temperature: 0℃~55℃
Size: In line with GE Fanuc series 90-30 module standard size
Other features:
4.78A Surge current (duration 10ms)
1V maximum output voltage drop
1mA maximum shutdown state leakage current
Functional features:
Flexible output configuration: The output of each channel can be configured independently to meet different control requirements.
High reliability: Industrial grade components are used to ensure stable operation of modules in harsh environments.
Easy to install: The module adopts the standard plug and pull design, easy to install.
A wide range of applications: suitable for a variety of industrial control occasions, such as machine tool control, packaging machinery, automated production lines, etc.
Application field:
Industrial automation: Control of motors, valves, sensors and other equipment.
Process control: to realize the monitoring and control of the production process.
Data acquisition: Field data acquisition and transmission to PLC.
