GE IC695ALG616The GE IC695ALG616 module is an analog input module manufactured by GE Fanuc Automation (now Emerson Automation Solutions), part of the PACSystems RX3i family. The module is mainly used in industrial automation systems to collect various analog signals, such as voltage, current, etc., and convert them into digital signals for PLC processing and control.
​Product name
English: GE Fanuc RX3i 16/8 channel analog input module

English: GE Fanuc RX3i Analog Input Module, 16/8 channel
Product description
The IC695ALG616 module has the following main functions:
​Analog signal acquisition: 16 or 8 channels of analog signals can be acquired simultaneously.
Signal conversion: The analog signal is converted to a digital signal for PLC processing.
Input type: Voltage and current input types are supported. You can configure them

based on actual requirements.
Isolation design: Each channel has isolation protection to improve the reliability of the system.
Flexible configuration: Multiple parameters can be configured through the software to adapt to different application scenarios.
Product parameters and specifications (partial, detailed parameters please refer to the product manual)
Number of channels: 16/8 channels (configurable)
Input type: Voltage/current
Input range: Various input ranges can be configured, such as 0-20mA, 4-20mA, +/-20mA, etc
Resolution: High resolution to ensure measurement accuracy
Sampling rate: Configurable
Input impedance: High input impedance, reducing the impact on the circuit under test
Isolation voltage: High isolation voltage, improve safety
