GE IC695ALG616

The GE Fanuc IC695ALG616 module is a non-isolated differential analog voltage/current input module for the RX3i series programmable logic controllers (PLCS). It is used to convert analog signals into digital signals for PLC processing. The module has the following features:

16 single-ended or 8 differential analog input channels
Supports a variety of input ranges, including 0-10V, 4-20mA, +/-10V, etc

High accuracy: ±0.1% full scale accuracy
High reliability: The redundant design ensures the normal operation of the module
The IC695ALG616 module is suitable for a variety of applications where analog signals need to be measured, including:

Temperature measurement
Pressure measurement
Flow measurement
Position measurement
Other industrial process control applications
Product parameters:

Parameter value
Number of input channels 16 single-ended or 8 differential
The input range is 0-10V, 4-20mA, +/-10V, and so on
Input accuracy ±0.1% full scale
Operating voltage 24V DC
Working current 2A
Operating temperature -40°C to 85°C
Dimensions 90 x 30 x 25 mm
Weight 150 g
