GE IC695ALG616

The GE Fanuc IC695ALG616 module is an analog input module for RX3i PACSystems series programmable logic controllers (PLCS). It is used to convert analog signals, such as voltages and currents, into digital signals so that PLCS can process them. The module has the following features:

16 single-ended or 8 differential analog input channels

Supports current and voltage input
High accuracy: ±0.1% full scale accuracy

High reliability: The redundant design ensures the normal operation of the module
The IC695ALG616 module is suitable for a variety of applications where analog signals need to be measured, including:

Temperature measurement
Pressure measurement
Flow measurement
Position measurement
Other analog signal measurement applications
Product parameters:

Parameter value
Number of simulated input channels 16 single-ended or 8 differential
Supported input signal current and voltage
Input accuracy ±0.1% full scale
Operating voltage 24V DC
Working current 2A
Operating temperature -40°C to 85°C
Dimensions 90 x 30 x 25 mm
Weight 150 g
