GE IC698PSA100

The GE IC698PSA100 is a PACSystem RX7i power module manufactured by Emerson Automation and formerly owned by GE Intelligence Platform (GE IP). The power module is installed in slot 0, the leftmost slot of the RX7i standard rack. It uses spiral input terminals and is designed for input voltages ranging from 85 to 264 VAC (nominal voltage 120/240 VAC) or 100 to 150VDC (nominal voltage 125 VDC) and frequencies from 47 to 63 Hz1. In addition, the module also has active overvoltage and overcurrent limiting functions to ensure the stable operation of the system1.

Product parameters and specifications:

Input parameters:

Input voltage range: 85 to 264 VAC (nominal voltage 120/240 VAC) or 100 to 150VDC (nominal voltage 125 VDC).
Frequency range: 47 to 63 Hz.

Output parameters:

Maximum output power: 100 watts (total power).
Output voltage and current:
5.1 VDC (nominal value), range 4.875 to 5.25 volts, 0-20 amps.
