GE IS200EACFG2A

The GE IS200EACFG2A module is a General Electric (GE) excitation controller AC feedback board for use in GE’s EX2100 series excitation control systems. The module is responsible for collecting and processing AC feedback signal, providing accurate feedback information for excitation control system, so as to realize excitation control of synchronous generator.

Product parameters and specifications:
Manufacturer: GE Industrial Systems

Series: EX2100 excitation control
Function: Collect and process AC feedback signal

Interfaces: There are usually multiple interfaces for connecting sensors, other control modules, and systems.
Voltage: Operating voltage range
Current: Maximum working current
Temperature range: Operating temperature range
Size: The physical size of the module
Weight: The weight of the module
The specific parameters may vary depending on the version or configuration. You are advised to refer to the official GE product manual.

Main functions:
Collect AC feedback signals: Collect AC voltage and current signals from the synchronous generator or other devices.
Signal processing: The collected signal is filtered, amplified, converted, etc., to obtain accurate feedback information.
Provide feedback signal: The processed feedback signal is provided to the excitation controller for closed-loop control.
