GE IS200TTURH1C
The GE IS200TTURH1C is an end board designed for GE Mark VI series turbine control systems. It is part of the GE Speedtronic family and plays an important role in turbine control systems. The module provides the interface between the exciter control interface board and the exciter bridge of the innovative series medium voltage SP driver, capable of connecting to the 3300V and 6600V versions of the driver.
Main function
Interface function: Provides the interface between the exciter control interface board and the medium voltage SP driver.
Signal connection: Connect discrete wired AC and DC inputs to create voltage feedback.
Current feedback: Run current feedback through the J2 connector.
MOV fuse loss detection: Detect the MOV fuse in the SCR bridge.
Status indication: LED indicators are provided to show SCR gate pulse, power and isolation power status, and MOV fuse loss.
Test points: Test points are provided for signal access and diagnosis of connector I/O signals.
Product parameters and specifications
Applicable system: GE Mark VI series turbine control system
Voltage: Support 3300V and 6600V drivers
Interfaces: Multiple plug-in connectors to connect discrete wired AC and DC inputs
Protection function: MOV fuse loss detection
Indicator function: LED indicator
Test points: Multiple test points
Others: 16 radiators, 11 high voltage electrolytic capacitors, etc
