GE IS215VPROH2BC

This section describes the GE IS215VPROH2BC module
Product overview
The GE IS215VPROH2BC module is a key component of the General Electric (GE) Mark VI Series control system, which is primarily used for turbine protection. It integrates input/output processing, logic operations and communication functions to provide comprehensive protection for the turbine.

Product name and description

Product name: GE IS215VPROH2BC turbine protection module
Description: This module is part of the GE Mark VI control system for emergency shutdown and protection of steam turbines. By monitoring various parameters, such as temperature, pressure, vibration, etc., once abnormal conditions are detected, it will send a signal to trigger protective measures to prevent equipment damage.
Main parameters and specifications

Functions: emergency shutdown, overspeed protection, overtemperature protection, vibration protection, etc.
Interface: Thinwire, RS-485, etc
Memory: 16MB DRAM
Processor: Pentium
Operating temperature: 0°C to 45°C
Certification: Meets relevant industry standards
Main function
Signal acquisition: The collection of analog and digital signals from various sensors.
Logical operation: According to the preset logical relationship, the collected signal is processed.
Alarm: When an abnormal situation occurs, an alarm signal is issued.
Emergency shutdown: In an emergency, a signal is sent to trigger the emergency shutdown of the turbine.
