GE IS220PDIOH1A

The GE IS220PDIOH1A is a digital input/output module that supports 16 input points and 16 output points. It is designed to work with GE RX3i programmable logic controllers (PLCS) to provide high-speed input and output capabilities for applications that require fast response times, such as high-speed assembly lines. The module is equipped with LED indicators that show the status of each input and output point, making it easy to troubleshoot any problems that may arise. In addition, the module features a rugged design that allows it to withstand harsh industrial environments. It is built to the highest industry standards and is certified for use in hazardous locations1.

Product parameters:

Input voltage: 24V DC nominal 1.
Input current: <30mA1.

Output voltage: 24V DC nominal 1.
Output current: 2A1 per channel.
Operating temperature: -20°C to +60°C1.
Storage temperature: -40°C to +85°C1.
Humidity: 5% to 95% (non-condensing) 1.
Dimensions: 15.2 x 10.4 x 3.2 cm 1.
Weight: 0.25 kg 1.
Product specifications (which may vary based on information from different sources) :

Electrical data interface: one or two 5-pin terminal interfaces, which comply with the CiA and ODVA recommendations. Supports the CAN BUS/DeviceNet/CANOpen bus standards. The communication rate can reach 1M2.
Optical fiber interface: Optical fiber wavelength includes multi-mode 850nm, 1310nm; Single mode 1310 nm, 1550nm. There are many types of transmission fiber to choose from, and the transmission distance can be up to 2Km for multi-mode and 20Km2 for single-mode.
Power supply and protection: dual power supply redundant input, DC(9-36)V, typical DC24V, power consumption less than 4W, with DC1500V voltage isolation and reverse protection function2.
Mechanical characteristics: The overall dimension is 132mm105mm52mm (high depth and width), the housing is IP30 protection grade, the corrugated aluminum reinforced housing is installed with 35mm guide rail, the net weight is 800g3.
Working environment: Working temperature optional range -10-70℃ (-40~+85℃), relative humidity ≤90% (non-condensing), storage temperature -40~ 80℃2.
Bus: VMEbus3.
I/O points: digital input 16 points, digital output 16 points, 2 relays, analog input 1 point, analog input range -10 V to +10 V3.
Data transfer rate: up to 10 MHz3.
Power supply voltage: +5 V, +12 V, -12 V3.
Power consumption: about 5 W3.
Protection class: IP303.
Dimensions: 233 mm x 167 mm3.
Weight: About 1 kg3.
