GE PCIE-5565RC-10000

The GE PCI-5565RC-10000 module is a high-performance PCI Express interface card manufactured by General Electric (GE). It is commonly used in industrial control systems that require high-speed data transmission and real-time performance. The module is designed to provide reliable, low-latency communication for use in a variety of harsh industrial environments.

Product name resolution

GE: Short for General Electric.
PCIE: PCI Express interface, a high-speed serial computer expansion bus standard.
5565RC: GE’s internal model designation for this family of products, which may represent its specific functional or technical characteristics.
10000: May represent a specific configuration or version of the module, such as memo

ry size, number of interfaces, etc.
Product characteristics
High-speed data transfer: provides continuous data transfer rates of up to 170 MB/s.
Low latency: Deterministic transmission with latency of only 450-500 nanoseconds.
High reliability: Adopts redundant transmission mode to effectively suppress errors.
Flexible configuration: Supports multiple packet sizes and transmission modes.
Industrial grade design: suitable for harsh industrial environments.
Main function
High-speed data acquisition: High-speed data acquisition from sensors or other devices.
Real-time control: Realize real-time control of industrial equipment.
Data transfer: Transfer of large amounts of data between different devices.
Network communication: Connect multiple nodes through optical fibers to build a high-speed network.
Product parameters (typical values, specific parameters refer to the product manual)
Interface: PCI Express
Data transfer rate: 170 MB/s
Delay: 450-500 nanoseconds
Memory: The value depends on the model
Connection mode: Optical fiber
Application field
Industrial automation: for high-speed data acquisition, control and communication.
Test measurement: For high-precision data acquisition and analysis.
