GE SR469-P5-HI-A20-T

The GE SR469-P5-HI-A20-T is a General Electric (GE) motor protection relay designed to protect motors from overload, short circuit, ground failure, and other damages. The relay has the following features:

Small size, easy to install

High precision, reliable action
Multiple protection functions to meet different application requirements
Meets IEC and NEMA standards

The relay is suitable for a variety of industrial applications, including:

Machine building
Chemical industry
The oil and gas industry
Electric power system
Building facility
Product parameters:

Rated current: 5A
Operating voltage: 240/480VAC
Protection type: overload, short circuit, ground fault
Action time: Overload: 0.5-10 seconds; Short circuit: 0.01-0.5 seconds; Ground fault: 0.1-1 seconds
Enclosure protection class: IP67
Operating temperature: -25°C to +70°C
Storage temperature: -40°C to +85°C
Dimensions: 57 mm x 57 mm x 28 mm
Weight: 0.15kg
Specifications:

Vibration resistance: 5 Hz to 350 Hz, 0.5 g RMS
Shock: 15 g, 30 ms pulse
Electromagnetic compatibility: Meets IEC and NEMA standards
Applications:

Overload protection: When the current of the motor exceeds the rated value, the relay will automatically disconnect the power supply to prevent the motor from overheating or damage.
Short circuit protection: When a short circuit fault occurs, the relay will immediately disconnect the power supply to prevent damage to the motor and other equipment.
Ground fault protection: When the motor’s housing is grounded, the relay will automatically disconnect the power supply to prevent electric shock.
