GE UR8FH

The GE UR8FH is a CT/VT module in the General Electric (GE) family of universal relays for the measurement and protection of current and voltage in power systems. The module has the following features:

High accuracy: Provides measurement accuracy up to 0.2%.

High reliability: Rugged design to withstand harsh environments.
Easy to use: provides an intuitive interface, easy to configure and use.

Product parameters:

Measurement type: current, voltage
Measurement accuracy: Current: 0.2%, voltage: 0.2%
Measuring range: Current: 5A to 5000A, voltage: 24V to 36kV
Communication interface: Ethernet, RS-232/RS-485
Operating temperature: -40°C to +70°C
Protection level: IP67
Dimensions: 222 x 176 x 64 mm
Weight: About 2.5kg
Product Specifications:

Comply with IEC 60044-1, IEC 61869, IEEE C37.110 and other standards
Supports DIN rail mounting
Application field:

Power system protection
Relay protection
Measurement system
Data acquisition system
