HITACHI LPU100H

HITACHI LPU100H is a control card module manufactured by HITACHI and belongs to the Hitachi PLC programmable controller MVH family of CPU modules. In addition to supporting USB and serial ports for PCS (RS-232C), it comes standard with Ethernet and USB memory ports1. The module supports 8 models in the 40-point and 64-point lineup, makes it easy to read/write programs via universal USB memory, and comes with data recording/tracking (CSV file saving) function12. In addition, the LPU100H module is also equipped with Modbus gateway function (Modbus-TCP≈Modbus-RTU protocol conversion function), with five high-speed counters (100kHz) and three pulse /PWM output (65kHz) channes12.

The main functions of LPU100H module include: receiving the input

signal given by the control target, calculating and outputting the calculation result according to the program content set by the user; Supply power to the body and start running the system, and continue to perform the above operations until the power is off or the system stops running; Information stored internally can be extracted or set as other information by an externally connected device; At the same time, when the system starts running, this information can be automatically initialized or saved by the user.

Product parameters:

Brand: HITACHI
Model: LPU100H
Memory: 280 KB (supports modular programming and the use of user-defined function blocks to help reduce design time) 3
Communication interface: Support RS-232C, RS-485, RS-422 (some models have) 1
