HONEYWELL FC-TSDI-1624

The Honeywell FC-TSDI-1624 module is a digital input module that is primarily used in Honeywell’s automation control systems. It is able to receive digital signals from field equipment, such as switching signals, relay status, etc., and convert these signals into digital signals that can be recognized by the control system. The module is usually installed in the control cabinet and connected to the field equipment to play the role of signal isolation and conversion.

Main function
Digital signal input: Receive digital signals from field equipment, such as switching signals, limit switch signals, etc.
Signal isolation: Isolate the field equipment from the control system to prevent interference.
Signal conversion: The digital signal is converted into a signal that the control system can recognize.
Fault diagnosis: Provides the self-diagnosis function to facilitate fault diagnosis and maintenance.
Product parameters and specifications (some parameters, please refer to the official information for details)

Parameter Name Parameter Value Unit description
Input channels 16 channels
Input Type Numeric input
Input voltage 24VDC Max V
Maximum input current 16mA mA
Operating temperature -20℃~70℃ ℃
Mounting method DIN rail

Export to Google Forms

Application scenario
Industrial automation: widely used in various industrial process control systems, such as chemical, petroleum, electric power and other industries.
Building automation: Used to control and monitor equipment in building automation systems.
Process control: used for signal acquisition and processing in process control systems.
