IS200ERSCG1A

The IS200ERSCG1A module is a field regulator signal conditioning module for processing signals from generators and other external devices. This module is commonly used with the excitation regulator assembly and the EPDM module, which provides 125 VDC voltage.

The IS200ERSCG1A module has the following features:

Support for Mark VI, Mark VII and Mark VIII excitation regulator assemblies

Supports multiple signal types, including current, voltage, power, and frequency
High precision and reliability
Have diagnostic function

Product parameters:

Dimensions: 220 mm x 100 mm x 50 mm
Weight: 2.0kg
Operating temperature range: -20°C to +70°C
Storage temperature range: -40°C to +85°C
Relative humidity: 5% to 95% (non-condensing)
Specifications:

Complies with IEEE Std 1309-2001 standard
Meets UL 508A standards
Meet CE standard
Applications:

Power station
substation
Industrial control system
Rail transit system
