LEM LC1000-S/SP7

Product Description:

This module is a closed-loop (compensated) current transducer that utilizes the Hall effect for electronic measurement of currents.
It’s designed to measure DC, AC, and pulsed currents, providing galvanic isolation between the primary (high-power) and secondary (electronic) circuits.
Essentially, it allows for safe and accurate measurement of high currents.
It is designed for printed circuit board mounting.

Product Parameters and Specifications:

Here’s a summary of key specifications:

Primary Nominal RMS Current (IPN): 1000 A
Primary Current Measuring Range (IP): 0 to ±3000 A
Conversion Ratio (KN): 1:4000
Supply Voltage (VC): ±24 V (±10%)
Frequency Bandwidth (-1 dB): DC to 100 kHz
Accuracy: Excellent accuracy, and very good linearity.
Response Time: Short response time.
Isolation: Galvanic isolation.
Applications:
- AC variable speed drives and servo motor drives.
- Static converters for DC motor drives.
- Battery supplied applications.
- Uninterruptible Power Supplies (UPS).
- Switched Mode Power Supplies. (SMPS).
