METSO D201190

The Metso D201190 module is an important component of Metso automation systems and is primarily used for communication between the control system and field instruments that support the HART protocol. It can convert the digital signal of the control system into analog signal and communicate with HART intelligent instrument through HART protocol.

Main function

HART communication: Realize communication with intelligent instrument of HART protocol, including configuration, parameter setting, data exchange, etc.
Analog signal output: the digital signal is converted into a 4-20mA standard analog signal to drive the actuator.
Diagnosis function: Provides self-diagnosis function to monitor module running status and discover faults in time.
Product parameters and specifications (some parameters, please refer to the official information for details)

Parameter Name Parameter Value Unit description
Model number D201190
Number of output channels 4
Output signal type 4-20mA
Communication protocol HART
Operating temperature ° C Indicates the operating temperature range of the module
