MITSUBISHI AJ65SBTB1-32T

The Mitsubishi Electric AJ65SBTF1-32T is a digital output module designed for Mitsubishi PLC systems. It is mainly used to convert the digital signal from the PLC into a transistor switching signal, so as to control the external load equipment, such as motors, solenoid valves, relays, etc. The module has the characteristics of high reliability, high speed and easy installation, and is widely used in the field of industrial automation.

Product parameters and specifications
Output points: 32 points

Output type: transistor drain type
Output voltage: DC12/24V (optional)
Output current: 0.5A/ point, 4.8A/1 common end
Response time: less than 1.5ms

Connection mode: Terminal block type
Installation method: Installed on Mitsubishi Q series PLC
Operating temperature: -10℃ ~ +55℃
Dimensions: Please refer to the product data sheet
Weight: Please refer to the product data sheet
Other parameters: Refer to the product data manual
Product characteristics
High density output: 32 points output, saving installation space.
Fast response: Short response time, suitable for high-speed control.
Flexible configuration: DC12V or 24V output voltage is available.
High reliability: suitable for harsh industrial environments.
Product application
Industrial automation: widely used in various industrial automation systems, used to control motors, valves, lamps and so on.
Machine control: used to control the start, stop, running state of the machine, etc.
Process control: In a process control system, used to control the actuator.
Matters needing attention
Compatibility: Must be used with Mitsubishi Q Series PLC.
Installation: Please strictly follow the product instructions during installation.
Wiring: Note the polarity of the output signal when wiring.
