MITSUBISHI FX2N-10GM

Mitsubishi FX2N-10GM module is a special module of Mitsubishi Electric FX2N series PLC, which is mainly used to achieve high-precision positioning control of motors. It can control the motor to move at a specific speed, acceleration and position according to the instructions of the PLC program, and is widely used in various automation equipment, such as CNC machine tools, packaging machinery, handling robots and so on.

Product parameters and specifications

Model: FX2N-10GM
Type: Single-axis positioning module
Number of control axes: 1 axis

Pulse output frequency: 1Hz ~ 1MHz
Position accuracy: high
Control mode: position control, speed control, torque control
Input/Output: digital input/output, analog input/output
Power supply voltage: 24V DC
Mounting method: DIN rail mounting
Other parameters: Please refer to Mitsubishi Electric official product manual for specific parameters
Main feature
High precision positioning: Positioning accuracy of micron level can be achieved.
High-speed response: high pulse output frequency, fast response speed.
Multiple control methods: to meet different control needs.
Easy to program: Compatible with FX2N PLC programming language.
High reliability: suitable for harsh industrial environments.
Application field
CNC machine tools: Control the movement of the tool.
Packaging machinery: control the sealing, cutting and other actions of the packaging box.
Handling robot: Control the joint movement of the robot.
Automated production lines: Control the movement of various actuators.
Matters needing attention
Load matching: Ensure that the output capacity of the module matches the motor.
Correct wiring: Correctly connect the module to the motor according to the instructions.
Programming: Familiar with FX2N PLC programming language, write the correct control program.
Environment: Install in a well-ventilated environment to avoid high temperature and high humidity.
