NI PXI-2532B

The NI PXI-2532B is a high-density PXI matrix switch module specifically designed for automated test systems with high channel counts. It uses a compact reed relay with extremely high switching speed and reliability to flexibly connect a variety of signal sources and measuring instruments for complex test configurations.

Main feature

High-density intersections: With 512 intersections, large-scale matrix configurations can be provided in a single 3U PXI slot.
High-speed switching: The switching speed of the reed relay is up to 2000 times/second, which can quickly switch the signal path.
Flexible configuration: Supports a variety of matrix topologies to meet various test requirements.
High reliability: the use of reed relay, with long service life and reliability.
Easy to program: Support NI Switch Executive software for easy configuration and programming.
Product parameters and specifications (some parameters, please refer to the official information

for details)
Parameter Name Parameter Value Unit description
Cross Points 512 maximum connection points
Switching speed 2000 times/SEC/SEC reed relay switching speed
Voltage/current Rating 100 VDC/100 Vp or 500 mA V/A Maximum withstand voltage and current
Interface type PXI Meets the PXI standard
Matrix configuration Supports multiple matrix configurations, such as 4×128, 8×64, and 16×32
