NI PXIE-5105

The NI PXIe-5105 is a powerful, high-performance digitizer module designed for a variety of data acquisition and signal processing applications. It uses advanced analog-to-digital converter (ADC) and digital signal processing (DSP) technologies to provide real-time sampling rates of up to 60 MS/s and analog bandwidth of 60 MHz, enabling accurate capture of high-speed and wideband wide signals.

The module has the following features:

High performance: real-time sampling rate up to 60 MS/s, analog bandwidth up to 60 MHz
High precision: 12 bit vertical resolution to ensure measurement accuracy

Multi-channel synchronous acquisition: 8 synchronous sampling channels can collect multiple signals at the same time
Large-capacity storage: Up to 512 MB of on-board storage can meet the needs of long-term data collection
Flexibility and extensibility: Supports the PXIe platform and can be used with other PXIe modules for more powerful functionality
Product parameters:

Model: PXIe-5105
Sampling rate: 60 MS/s
Bandwidth: 60 MHz
Resolution: 12 bits
Number of channels: 8 channels
Storage: 512 MB
Interface: PXIe
Operating temperature: -20°C to +65°C
Size: 1 PXIe slot
Weight: 0.3kg
Product Specifications:

Comply with IEC 61131-3 standard
After strict testing and quality control
