NI PXIE-5105

The NI PXIE-5105 is a high-performance PXIe oscilloscope module from National Instruments (NI). It is a multi-channel, high sampling rate digitizer, widely used in test and measurement, control systems, aerospace and other fields, for the acquisition and analysis of high-frequency analog signals.

Product name
NI PXIe-5105 high-density PXI oscilloscope
Product description
The PXIe-5105 module features eight synchronous sampling channels that allow simultaneous acquisition of multiple signals and provides flexible coupling, impedance, voltage range, and filtering Settings. Its high sampling rate and high resolution enable it to accurately capture rapidly changing signals, making it suitable for a variety of high-frequency signal measurement applications.

Product parameters and specifications
Number of channels: 8
Sampling rate: up to 60 MS/s

Resolution: 12 bits
Bandwidth: 60 MHz
Trigger mode: A variety of trigger modes, including edge trigger, pulse trigger, etc
Memory: High capacity onboard memory, can store a large amount of collected data
Interface: PXIe interface that can be used with other PXI or PXIe modules
Main feature
High density: 8 channels are integrated in a compact module, increasing the channel density.
Synchronous sampling: All channels are sampled synchronously, ensuring time alignment.
Flexible configuration: Multiple configuration options are available to suit different measurement requirements.
High performance: High sampling rate and high resolution to meet the requirements of high-precision measurement.
