NI PXIE-5105

The NI PXIE-5105 is a high-performance PXIe oscilloscope module manufactured by National Instruments (NI). It is widely used in the fields of test measurement, research and development, and is used to collect and analyze various analog signals.

Product description
The PXIe-5105 features eight synchronous sampling channels that provide flexible coupling, impedance, voltage range, and filtering Settings. With its high sampling rate and high resolution, the module is suitable for applications requiring high-speed, high-precision measurements. In addition, it has a powerful trigger function, large onboard memory and rich software support, making it easy for users to perform signal acquisition, analysis and processing.

Product parameters (part)
Maximum sampling rate: 60 MS/s
Analog bandwidth: 60 MHz

Number of channels: 8
Vertical resolution: 12 bits
Onboard memory: Multiple configurations are available
Trigger mode: A variety of trigger modes, including edge trigger, pulse trigger, etc
Interface: PXIe
