NI PXIE-5105

The NI PXIE-5105 is a high-performance PXIe oscilloscope module manufactured by National Instruments (NI). It has a wide range of applications in semiconductor testing, aerospace, automotive electronics and other fields.

Product name and model

Product name: NI PXIe-5105 high-density PXI Oscilloscope
Model: PXIe-5105
Product description
The PXIe-5105 module features eight synchronous sampling channels that provide flexible coupling, impedance, voltage range, and filtering Settings. It is suitable for applications requiring high sampling rate, multi-channel synchronous acquisition. The module is usually integrated in the PXI or PXIe chassis and realizes signal acquisition, analysis and processing through software control.

Product parameters (part)
Maximum sampling rate: 60 MS/s
Analog bandwidth: 60 MHz
Number of channels: 8
Vertical resolution: 12 bits
Onboard memory: 16MB, 128MB, or 512MB
Trigger mode: A variety of trigger modes, including edge trigger, pulse trigger, etc
Interface: PXIe
