NI PXIE-6368

Description of the NI PXIe-6368 module

Product overview

The NI PXIE-6368 module is a multi-function data acquisition (DAQ) module produced by National Instruments (NI), a member of the PXIe family. It integrates analog input, analog output, digital I/O and counter/timer functions for a variety of test and measurement applications.

Product functions and features

Multi-functional integration: analog input, analog output, digital I/O and counter/timer functions are available to meet a variety of measurement needs.

High sampling rate: Support up to 2 MS/s sampling rate, able to capture high-speed signals.

Synchronous sampling: Multi-channel synchronous sampling to ensure data consistency.

Flexible configuration: With the NI-DAQmx software, various parameters of the module can be flexibly configured.

PXIe Standard: Meets the PXIe standard and can be used with other PXIe modules and controllers to build flexible test systems.

Main parameters and specifications

Model: PXIe-6368

Brand: NI

Type: Multifunctional data acquisition module

Analog input: 16 channels, 16 bit resolution, 2 MS/s sampling rate

Analog output: 4 channels

Digital I/O: 48 lines

Counter/timer: Versatile

Interface: PXIe

Operating temperature:… (Please refer to product data sheet for details)

Size:… (Please refer to product data sheet for details)

Product description

The NI PXIe-6368 module is a high-performance, versatile data acquisition module for a variety of test and measurement applications, such as:

Communication test: ISDN, ADSL, POTS, etc

Ultrasonic and sonar testing

High energy physics experiment

Transient recording
