NI PXIE-6548

The NI PXIe-6548 is a high-performance digital waveform instrument designed to generate and analyze digital signals. It is widely used in electronic testing, communication, automation and other fields, for equipment simulation, digital protocol testing, digital signal processing and so on. With up to 32 digital channels, the module can simultaneously capture and generate high-speed digital signals, and provides rich trigger and synchronization functions.

Product parameters and specifications (Specific parameters may vary depending on the model and configuration, please refer to the official document)
Model: PXIe-6548
Brand: NI (National Instruments)
Type: Digital waveform instrument
Number of channels: 32 single-ended digital channels
Sampling rate: up to 400 MHz
Signal generation rate: up to 400 Mbits/s
Voltage range: Programmable, 1.2V-3.3V
Trigger: has a variety of trigger modes, including edge trigger, pulse width trigger, etc
Synchronization: Supports multiple synchronization modes to synchronize with other devices
Interface: PXI Express interface
Software: Support NI LabVIEW and other software for programming control

Main feature
High-speed sampling: It can collect digital signals at a high sampling rate, which is suitable for the test of high-speed digital circuits.
High precision: High sampling accuracy to ensure the accuracy of test results.
Flexible configuration: Software can be flexibly configured to meet different test requirements.
Rich functions: Provides a variety of trigger, synchronization, and analysis functions to meet complex test requirements.

Easy to use: Equipped with a wealth of software tools, convenient for users to program and operate.
Application field
Digital circuit test: used to test the function, performance and reliability of digital circuits.
Communication protocol test: Used to test the compatibility of various communication protocols.
Embedded system testing: Digital interfaces for testing embedded systems.
Digital signal processing: used to collect, analyze and process digital signals.
