NI SCXI-1001

The NI SCXI-1001 is a rugged 12-slot AC chassis designed for SCXI (Signal Conditioning Extension Interface) systems. It provides power to the SCXI module and handles all timing, triggering, and signal routing between modules and between modules and other devices. The SCXI-1001 chassis provides users with a flexible, scalable platform for building a variety of measurement and automation systems.

Product parameters and specifications (typical values, please refer to the official manual for specific parameters)
Number of slots: 12

Power supply: AC power supply. Refer to the manual for specific voltage and frequency
Cooling method: forced air cooling
Size: Standard chassis size, please refer to the manual
Weight: Approx. 10kg (specific weight depends on configuration)
Environmental requirements: Industrial environment, please refer to the manual

Key characteristics
High performance: Provides stable power supply and accurate signal routing to ensure the accuracy of measurement data.
Scalability: Supports up to 12 SCXI modules, which can be flexibly expanded according to application requirements.
Modular design: Modular design allows users to replace or add modules as needed.
Low noise: Low noise design to reduce measurement errors.
Rugged: suitable for harsh industrial environments.
Application field
Data acquisition: high-speed, high-precision data acquisition system.
Test and measurement: electronic products, instruments and other test and measurement
