NI SCXI-1193

NI SCXI-1193 module: Details
Product Name:

NI SCXI-1193 10-channel thermocouple /RTD module

NI PXI/PXIe extension module
NI data acquisition module
Product Description:

The NI SCXI-1193 module is a high-performance, high-precision data acquisition module designed for the NI PXI/PXIe platform. It offers 10 general-purpose thermocouples and RTD input channels that can be used to measure a variety of temperature applications. The module has the following features:

High accuracy: Measuring accuracy up to 0.025°C per channel
Wide range: Supports multiple thermocouple and RTD types
Cold end compensation: Automatically compensates the cold end temperature
Filter function: can eliminate noise and interference
Trigger function: Supports external trigger
Product parameters:

Number of channels: 10
Measurement type: Thermocouple, RTD
Measurement accuracy: 0.025°C
Range: Depends on thermocouple or RTD type
Cold end compensation: automatic
Filtering function: low-pass, high-pass, band-pass
Trigger function: external trigger
Specifications:

Dimensions: 100 mm x 160 mm x 21 mm
Weight: 230 g
Operating temperature: 0°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Protection class: IP30
Application field:

Temperature measurement
Thermal analysis
Environmental monitoring
Industrial control
