NI SCXI-1193

The NI SCXI-1193 is a high-density, 32-channel RF multiplexer switch module manufactured by National Instruments (NI). It is mainly used to connect data acquisition devices and sensors or actuators to achieve signal transmission and data acquisition. SCXI-1193 module adopts shielded cable design, which can effectively suppress noise and ensure signal integrity.

Product parameters and specifications:
Number of channels: 32

Connector type: MCX
Frequency range: DC-500 MHz
Insertion loss: Typical value ≤ 0.5dB
Isolation: Typical value ≥ 60 dB
Switching time: Typical value ≤ 10 ms
Control mode: software programming control

Ambient temperature: 0°C to 55°C
Features:
High density: 32 channels are integrated in a compact module, improving system integration.
High frequency performance: suitable for switching and measurement of high frequency signals.
Flexible configuration: It can be configured to various topologies through software programming to adapt to different application requirements.
High reliability: The use of high-quality components and rigorous manufacturing process to ensure the long-term stable operation of the module.
Application field:
Wireless communication: Used to test the RF performance of wireless communication equipment.
Electronic measurement: Used to measure the RF parameters of various electronic devices.
Aerospace:
