OKOS AL8XGTE-3

The OKOS AL8XGTE-3 is a high-performance sampler board designed for high-speed data acquisition. It is able to capture analog signals at extremely high sampling rates and convert them into digital signals for easy subsequent analysis and processing. The module is widely used in radar, electronic warfare, communication, remote sensing and other fields, for signal analysis, data acquisition and so on.

Product parameters and specifications:
Sampling rate: Up to 3 GS/s (3 billion samples per second), capable of capturing rapidly changing signals.
Resolution: 8 bits for high accuracy.

Number of channels: Single channel, suitable for single signal acquisition.
Interface: PCI Express x1, easy to connect with the computer.
Memory: There are a variety of on-board memory options, ranging from 512MB to 2GB, which can be selected according to requirements.
Trigger mode: Supports multiple trigger modes, including software trigger, hardware trigger, and edge trigger, flexibly adapting to different application scenarios.
Other features:
Pre-trigger and post-trigger functions: Capture data before and after triggering events.
Fast retrigger time: High frequency sampling is possible.
Multiple interfaces: Supports multiple data transmission interfaces.
Main functions:
High-speed data acquisition: Acquisition of analog signals at extremely high sampling rates.
Data storage: The collected data is stored in the onboard memory.x

Data transfer: Data is transferred to the computer via PCI Express interface.
Trigger control: Flexibly control data acquisition according to trigger conditions.
Application field:
Radar: Reception and processing of radar signals.
Electronic Warfare: Analysis and jamming of electronic signals.
Communication: Monitoring and analysis of communication signals.
