PFCL201CE-50KN

ABB PFCL201CE-50KN: This is a force sensor produced by ABB, the specific model PFCL201CE-50KN.
Product description

The ABB PFCL201CE-50KN is a pillow force sensor commonly used to measure the tension of strips or wires. It is based on the Pressductor® magnetoeffect principle, which measures changes in the magnetic field to reflect the force applied to the sensor. The sensor is robust and durable for use in harsh industrial environments.

Main features:

High accuracy: High measurement accuracy with Pressductor® technology.
Durability: All stainless steel construction, corrosion resistance, suitable for harsh environments.
Easy installation: It can be installed directly under the bearing seat to measure the vertical force.
Wide measuring range: bidirectional force can be measured.
Application field:

Metal processing industry: steel strip, aluminum strip and other metal material tension measurement.
Paper industry: paper tension measurement.
Textile industry: fiber, yarn tension measurement.
Packaging industry: film, cardboard tension measurement.
Product parameters and specifications
Specific parameter specifications vary depending on the model and configuration. The following are some common parameter examples:

Measuring range: 50kN (depending on model)
Accuracy: 0.5%FS (Full Scale, Full scale)
Output signal: Usually mV/V or 4-20mA
Temperature range: -20℃ to +80℃
Protection level: IP67
