RCM470LY-13A
The RCM470LY-13A module is a ground fault monitoring module produced by Bender Company, which is mainly used to detect ground faults in electrical systems. It is an important safety protection equipment, which can send an alarm signal in time when a grounding fault occurs, and take corresponding protective measures to prevent personnel from electric shock and equipment damage.
Product name resolution
RCM: Residual Current Monitor.
470LY-13A: This section is the specific model assigned by Bender Company for this module, which contains information about the module version, specifications, etc.
Product description
The main functions of the RCM470LY-13A module include:
Grounding fault detection: Detects whether there is a grounding fault by measuring the leakage current in the loop.
Alarm signal output: When a ground fault is detected, an alarm signal will be issued to remind the operator.
Relay output: The relay can be driven to achieve disconnection of the circuit or other control actions.
Parameter setting: The module sensitivity, delay time and other parameters can be set.
Product parameters and specifications (typical values, refer to the product data sheet)
Rated current: 10A
Rated voltage: 90-132VAC
Leakage current sensitivity: 10mA
Output contact: Multiple relay output points
Operating temperature: -25℃ ~ +60℃
Installation method:
