S-073N 3BHB009884R0021

The S-073N 3BHB009884R0021 module is usually a phase module in the high voltage inverter produced by ABB. This module is one of the core components of the inverter, which is responsible for converting alternating current into direct current, and then converting direct current into alternating current with adjustable frequency and voltage, so as to achieve precise control of the motor speed.

Product name
Chinese name: ABB high voltage inverter phase module

Name: ABB Phase Module
Product description
The S-073N 3BHB009884R0021 module is the phase module used by the higher voltage level inverter in the ABB ACS6000 series. It adopts modular multilevel converter (MMC) technology, which has the characteristics of high efficiency, reliability and high precision. The module is usually used in large industrial equipment, such as wind power generation, mining machinery, etc., which requires high power density, reliability and control accuracy of the inverter.

Product parameters and specifications
Voltage level: High voltage (refer to the product manual for specific voltage levels)
Power: Depending on the specific model, the power range is large
Cooling method: forced air cooling or water cooling
Control mode: digital control, with accurate voltage, frequency control functions
Protection function: over current, over voltage, overheating and other protection functions
Communication interface: Supports a variety of communication protocols, such as Modbus, PROFIBUS, etc
Product characteristics
High efficiency: MMC technology is used to reduce the loss and improve the energy conversion efficiency.
High reliability: The use of high-quality components, through rigorous testing, to ensure long-term stable operation.
High precision: With accurate voltage and frequency control capabilities, to meet the high precision control requirements.
Modular design: easy installation and maintenance.
Strong adaptability: suitable for all kinds of harsh environments.
